1. The Tunnel freezer is widely used in quick-freezing strip, cubic or grain food, such as ice cream, shrimp meat, shrimp, sliced fish, meat dumpling, divided meat and chicken,.
2. Short freezing time, adopted the good effect cross ventilation, with the frozen time 10 to 50mins.
3. Matched with double speed electric motor, widen the use bound as well as saving the energy.
4. Air blower is divided into cross blast from right and left, mixed blast and top blast according to different frozen products which makes perfect freezing, quality and efficiency
2. Short freezing time, adopted the good effect cross ventilation, with the frozen time 10 to 50mins.
3. Matched with double speed electric motor, widen the use bound as well as saving the energy.
4. Air blower is divided into cross blast from right and left, mixed blast and top blast according to different frozen products which makes perfect freezing, quality and efficiency
Tunnel freezer Main Structure:
(1) Stainless steel conveyor belt;
(2) Sandwich PUF panels 150mm thick, laminated by stainless steel sheet both sides; floor panels are equipped;
(3) Doors are equipped with frame heating device;
(4) Aluminum evaporators, different fin pitches;
(5) Axial fans: stainless steel air box, aluminum blades;
(6) Full welded stainless steel water discharging plate is installed on top of floor panels. It will bring defrosting water out of cabinet through stainless steel draining pipes;
(7) The inlet device, outlet device and all structure parts are made of stainless steel;
(8) Schneider or Siemens electric components;
FSW300Tunnel freezer Parameters:
Frozen food :fish
Capacity: 300kg/h
Freezer Room Size: L*W*H(M) 10*2.3*2.4
Exterior Size: L*W*H(M) 11.6*2.3*2.4
Power:7.5kw
In Feed Temperature( ºC ): +15
Out Feed Temperature( ºC ): -18
Inner Circulation Temperature(ºC):-35
Frozen Time(min): 10-50
Refrigerant: R717/R404A
Main Electric Brand: Schneider
