China factory supply block ice maker machine,block ice making machine for fishery

FOB Price

US $80000.001 - 2 set

US $40000.003 - 10 set

group name: FIM Series Ice maker machine

Min Order: 1 set

brand name: First cold chain + freeze food machine

model: Block ice maker

Nearest port for product export: Tianjin Port, Shanghai Port, Ningbo Port, Qingdao Port

Delivery clauses under the trade mode: FOB, CFR, CIF, EXW, CIP, DDP, DAF

Acceptable payment methods: T/T, L/C

update time: Sun, 19 May 2024 06:44:07 GMT

contact supplier

Paramtents

Application Fields Food Processing
Condition New
Ice Shape Block ice
Refrigerating System Brand Compressor Unit
Cooling Way Air cooling or water cooling
Certification ISO, CE, CCC
Automation Automation
Transport Package Seaworthy Plywood Case

Packging & Delivery

Min Order1 set

Briefing

Block ice machinery Mainly used in food preservation, widely used in restaurants, supermarkets, pharmaceutical industries

Detailed

Block Ice Maker Machine Features

1.Superb Stability and reliability,long use life

Advanced workmanship and new technology makes high quality tube ice machine, you can always turst on. Rugged, heavy-duty design offers years of trouble-free operation.

2.Energy-efficient and cost saving

The elaborately designed and equipped ice tubers offers a smooth operation,with high efficiency to fulfill the energy-saving

3.Unique Vivid H-M Interactive control system

Give use access to the automatic electrical system which performs sequences for freezing and thawing precisely and dependably then makes great convenience to the customer to operate the machine and settle the trouble

(1).Delicate welding technics with X-RAY./Never leak.

(2).SS 304(Stainless steel) Ice making drum.(generator)

(3).All the material meet the HACCP request.

(4).With the unique water distribution pan and air mouth,pure water evenly flows to the tube wall of the evaporator spirally, which improves the efficiency of heat transfer.

(5).As soon as ice off, the water of low temp. is using for ice-making,which saving energy & increasing the drum volume of production of ice.

(6).Air pressure control excludes the risk of rupture of the evaporator drum.

(7).All the running status playing live in touch-screen, convenient as your family air-conditioning.

(8).Perfect failure &trouble-shooting querying system with red warning signal flicker if any failure occurred.

(9). Stop-time could be set at your will.

(10).The thickness of the tube ice could be adjusted with setting the icing time.

Application Field

Freezing drinks, mix wines. Cool foodstuffs, make ice pastries and keep fresh.

Widely used in hotel, bar, KTV, restaurant, catering, supermarket, ballroom, etc.

Food production process

Fishery,Aquatic product and Poulty meat processing

Vegetable delivery and preservation

Chemical industry process, etc

Model	FST-1.0-120-25	FST-2.0-240-25	FST-3.0-360-25	FST-2.5-100-50	FST-5.0-200-50
Capacity (kg/24h)		3000	6000	9000	5000	10000
Refrigerant		R404a / R717 / R22
Voltage		380v/3P/50Hz
Compressor	Brand	Hanbell or Frascold
	Refrigeration(kw)	27	43	56	43	78
	Power(kw)	15	22	37	22	37
	Model	Piston compressor &Screw compressor
Temperature	Environment Temperature(℃）	25(℃）
Temperature	Injection water temperature(℃）	20(℃）
Condenser	Fan power(kw)	0.75	1.5	3	1.2	3
Condenser	Cooling type	Plate evaporative cooling (Water cooling + Air cooling )
Time	Freezing time	7 hours			10 hours
Time	Unloading time	0.5 hours
Size	Ice tube weight(kg)	25			50
	Ice tube size(mm)	320125750			3701601000
	Machine size(mm)	438016002420	490020002500	554022502460	420022502450	600022502600
Net weight	kg	3500	4500	6500	5000	7500
