High Quality Full Automatic Frozen French Fries Production Line in China
- FOB Price
US $150000.01 - 1 set
US $10000.02 - 5 set
- group name
- Frozen french fries products line
- Min Order
- 1 set
- brand name
- First cold chain + freeze food machine
- model
- Frozen Potato Chips Line
- Nearest port for product export
- Tianjin Port, Shanghai Port, Ningbo Port, Qingdao Port
- Delivery clauses under the trade mode
- FOB, CFR, CIF, EXW, CIP, DDP, DAF
- Acceptable payment methods
- T/T, L/C
- update time
- Thu, 21 Nov 2024 17:38:56 GMT
Paramtents
Material 304 stainless steel
Power source Electric
Size Customized
Voltage 380V
Specification CE ISO9001
Transport Package Seaworthy Plywood Case
Country of origin China
Packging & Delivery
-
Min Order1 set
Briefing
Detailed
Brief Introduction of Frozen French Fries Production Line
♡ This is a fully automatic production line to produce frozen French fries from fresh potatoes.
♡ Such as for the 300-500kg/h production line:
-- The land needed to install the production line is 200 square meters(do not include the freezing part).
-- The length of the entire production line is 47 meters(do not include the freezing part).
-- Water consumption: 0.3 cubic meters per hour.
-- Labor needed: 3-4 (one people work at the beginning of the production line to feed potatoes into the elevator, another two people work at the two choosing machines to choose the unqualified potatoes, and at the packing machine need one people to collect the final packed bags).
-- Electric consumption is 155Kw.h(do not include the freezing part).
-- Oil consumption is 8 liters per hour(any kind of cooking oil is available, such as: sunflower oil, corn oil, bean oil, peanut oil, rapeseed oil, etc.).
♡ All the machines in the production line are made of stainless steel 304
♡ Electricity power requirement is 380V/50Hz/three-phase.
♡ The cutting machine can cut the potato sticks of thickness 2-10mm, it is adjustable.
♡ The packing machine is an automatic one and it can feed, elevate, weigh, and pack the fries at one time.
Storage Guide for Frozen French Fries
☞ At - 18°C until date printed on the packaging.
☞ At - 12°C 1 month.
☞ At - 6 °C 1 week.
☞ Once defrosted do not refreeze!
Overview of French Fries Tunnel Instant Freezer
The tunnel instant freezer could refrigerate the French fries to keep it fresh for long time storage. The frozen French fries keep the original taste and are crispier. It can make the temperature of the French fries to -18℃ within 20 minutes. You can frozen the French fries first and then pack them, also can pack them into bags and then frozen them.
Technical Data for 500kg/h Frozen French Fries Line
Name | Model | Power | Weight | Dimensions |
Feeder machine | SL-500 | 0.75Kw/380V | 60kg | 2000*900*1700mm |
Cleaning and Peeling Machine | QPJ-2000 | 3.7Kw/380V | 500Kg | 2100*850*1600mm |
Double Cutting machine | QDJ-1500 | 3Kw/380V | 160Kg | 1070*560*900mm |
Blanching Machine | PT-2000 | 15 Kw/380V | 300Kg | 9000*1000*1200mm |
De-watering machine | TS-1500 | 9Kw/380V | 500Kg | 5000*900*950mm |
Frying machine | YZJ-1000 | 60 Kw/380V | 600Kg | 9000*1000*2200mm |
De-oiling Machine | TS-1000 | 9Kw/380V | 500Kg | 5000*900*950mm |
Quick Freezer | FSLD500 | 22Kw/380V | 4500Kg | 7*4.2*3m |
Packaging Machine | 10 head automatic packing machine | |||
