China's Leading IQF Freezer Supplier for Frozen strawberries - Cost-Effective Fluidized Bed Freezer

China's Leading IQF Freezer Supplier for Frozen strawberries - Cost-Effective Fluidized Bed Freezer
China's Leading IQF Freezer Supplier for Frozen strawberries - Cost-Effective Fluidized Bed FreezerChina's Leading IQF Freezer Supplier for Frozen strawberries - Cost-Effective Fluidized Bed FreezerChina's Leading IQF Freezer Supplier for Frozen strawberries - Cost-Effective Fluidized Bed FreezerChina's Leading IQF Freezer Supplier for Frozen strawberries - Cost-Effective Fluidized Bed FreezerChina's Leading IQF Freezer Supplier for Frozen strawberries - Cost-Effective Fluidized Bed Freezer
FOB Price

US $200000.01 - 2 set

US $50000.03 - 3 set

group name
FSLD Series IQF freezer
Min Order
1 set
brand name
First cold chain + freeze food machine
model
FSLD
Nearest port for product export
Tianjin Port, Shanghai Port, Ningbo Port, Qingdao Port
Delivery clauses under the trade mode
FOB, CFR, CIF, EXW, CIP, DDP, DAF
Acceptable payment methods
T/T, L/C
update time
Tue, 09 Dec 2025 04:47:41 GMT

Paramtents

  • Refrigerant Freon

  • Structure Assembled

  • Suitable for Factory

  • Refrigeration System Brand Compressor Unit

  • Size Customized

  • Use Nature Production

  • Usage Vegetable & Fruit

  • Freezer Body Material 304 Stainless Steel

  • Specification CE ISO9001

  • Transport Package Seaworthy Plywood Case

Packging & Delivery

  • Min Order1 set

Briefing

Fluidized IQF freezers are mostly used for fruits & vegetables freezing, better freeze effective .
high degree automatic.

Detailed

Lock in the Freshness of Strawberries! First Cold Chain High-Efficiency Fluidized Bed (a freezing technology that suspends food in cold air for uniform cooling) Strawberry Freezer, Setting a New Benchmark for Freezing

Plump and juicy strawberries are nature's sweet gift, but their delicate pulp makes preservation an industry challenge—whether for small-scale family farms supplying local farmers' markets, medium-sized cooperatives processing berry products, or large food enterprises producing ready-to-eat fruit platters. Traditional freezing methods often cause fruit adhesion, cell rupture, mushy texture after thawing, and loss of flavor. Now, the high-efficiency fluidized bed strawberry freezer launched by First Cold Chain is tackling these processing pain points with cutting-edge technology, locking in the natural freshness of every strawberry and emerging as the preferred equipment across the strawberry deep processing sector.

As a seasoned player in the cold chain equipment field, First Cold Chain has always focused on the core goal of "high-efficiency preservation and industrial empowerment". This strawberry freezer is a concentrated embodiment of its technical strength. Designed based on the physical properties of strawberries, the equipment builds a full-chain freshness-preserving barrier through three core advantages, turning the freezing process into a key link for "freshness locking".
High-efficiency fans combined with optimized heat exchange design enable more precise and sufficient cold transfer. Equipped with customized high-efficiency fan units, the equipment creates a stable and uniform high-convection air field. Cooperated with the heat exchange structure optimized by fluid mechanics, the effective heat exchange area is increased by more than 30% compared with traditional equipment. Cold energy can quickly penetrate into the interior of strawberry pulp, avoiding the problem of excessive surface frosting while insufficient internal freezing. It not only improves the freezing efficiency by 40% but also significantly reduces unit energy consumption, saving operating costs for enterprises.
Advanced vibrating feeding system achieves a breakthrough in Individual Quick Freezing (IQF, a method that freezes each food item separately to prevent clumping) of strawberries. Aiming at the characteristics of strawberries such as uneven size and vulnerability to damage, the equipment adopts an intelligent frequency-modulated vibrating feeding method. By precisely controlling the vibration frequency and amplitude, strawberries remain evenly dispersed during transportation without stacking or squeezing. Each strawberry can fully contact with cold energy, forming an independent ice crystal layer, which completely solves the industry pain point of "clumping and adhesion" in traditional freezing. No secondary separation is required in subsequent processing, greatly improving production efficiency.
Rapid freezing locks in the original flavor, reviving the natural sweetness of strawberries— a critical advantage for diverse application scenarios. For frozen fruit snack manufacturers, it ensures strawberries retain their firm texture and bright luster in packaging; for jam and sauce producers, it preserves the rich fruit aroma that defines high-quality products; for catering chains preparing pre-made smoothies or dessert toppings, it guarantees consistent taste without excess juice loss. Relying on high-efficiency heat exchange and uniform fluidized bed freezing technology, the equipment realizes "rapid passing through the maximum ice crystal formation zone (the temperature range where large ice crystals easily form, damaging food cells)", generating small and uniform ice crystals in the intercellular spaces, which effectively prevents juice loss caused by cell rupture. Frozen strawberries not only maintain intact shape and bright color as fresh-picked ones but also retain plump texture and rich fruit aroma after thawing, providing high-quality raw material support for downstream products such as jam, dried fruit, and quick-frozen fruit plates.
From the field to the workshop, from fresh harvests to frozen storage, First Cold Chain's high-efficiency fluidized bed strawberry freezer safeguards the strawberry processing industry with technological innovation. It adapts seamlessly to various application scenarios: handling batch freezing of fresh strawberries for small cooperatives during peak harvest seasons, supporting continuous production lines for large enterprises manufacturing frozen berry mixes, and even meeting the precise freshness requirements of premium organic strawberry processors. Whether it is small and medium-sized strawberry cooperatives or large-scale food processing enterprises, this equipment can become a powerful assistant in improving product quality and market competitiveness with its high efficiency, energy saving, and stability. Choosing First Cold Chain means choosing freshness and reassurance, allowing every strawberry to retain the natural sweetness bestowed by nature during freezing.

FSLD1000 IQF FREEZER TECHNICAL PARAMETERS


Product

Frozen strawberries

Capacity

1000kg/h

In/Out Temp.

+10℃ to -18

Freezer Temp.

-35

In/Out Time

10-50min

Refrigerant

R507A

Consumption

200kw

Freezing Container Thickness

150mm

Product Height

≤100mm

Belt Width

1200mm

Product Input Conveyor/Output Conveyor

1000mm/800mm

Water Input Pressure

≥3 kg/cm2

Freezer Power

38.2KW

Freezer SizeL*W*H

12500×4000×3300mm

Freezer Body Material

Duplex stainless steel polyurethane insulation board density or 40 kg/m3, the thickness of 150 mm, 304 stainless steel outer plate thickness more than 0.5 mm

Main Electric Brand

Schneider(France) Siemens DLX etc

Belt and Speed

Food-grade stainless steel belt; Frequency conversion stepless speed regulation

Slide Track Material

Ultrahigh molecular polyethylene material.

Internal Structure

All made of 304 Stainless Steel Material, Argon arc welding

Evaporator

Effective from large aluminum finned tube set, stainless steel panel stent

Fan and Motor

Aluminum alloy stainless steel duct fan low noise and waterproof electric power consumption
