2. Size: Customization.
3. Functions: Fresh-keep, freezing, quick-freezing, fire-proof, explosion-proof, air-conditioning are all available
4. Good performance, low noise and high reliability
5. World renowned brand refrigeration accessories, guarantee long use cycle.
6. The automatic high precision digital controller is easy to operate with high efficiency...
7. Adjustable indoor temperature saves up to 30% electricity.
Classification:
Cold storage temperature: -5 º C ~ + 10 º C
Freezer storage temperature: -25 º C ~ + 18 º C
Quick-frozen storage temperature: -40 º C ~ + 18 º C
The Constant temperature: Customer's request
Storage of produce: Customer's request
Application fields:
Biology, industry, military, food, florist, farming, medicine, logistics, hospitality, and food processing.
Evaporator type
Air Cooled Type | Ceiling type DL (5-20℃）DD（-5~+5 ℃）DJ（-18~-20℃） |
|---|---|
Aluminum shelving | Customize -18 ℃ or -35℃ |
Evaporator Cooled Type | Evaporator Condenser DJS (-30~-40℃) |
Room size type
Room size | Mini | Small | Middle | Big |
|---|---|---|---|---|
Volume range | 200m³ | 200~1000m³ | 1000~5000m³ | >5000m³ |
Temperature table for reference
Cold storage goods | Temperature range |
|---|---|
Processing room | 10℃ |
Fruit, vegetable, dry food | 0~-5℃ |
Medicine, cake, pastry, chemical material | 0~-5℃ |
Ice storage room | -5~-10℃ |
Fish, meat storage | -18~-25℃ |
Deep freezer. | -25C~-35℃ |
Compressor type and condenser
Compressor type | Bitzer(Germany) | Frascold (Italy) | Copeland (US) | China brand |
|---|---|---|---|---|
Condenser | Air cooled | Aater cooled | Evaporator | |
Panels information
Office Foam panel | 50mm thickness |
|---|---|
Processing room 10℃ | 50mm/ 75mm PU |
-5℃ | 75mm/ 100mm PU |
-18℃ | 100mm/ 150mm PU |
-25C/ -35℃ | 150mm/200mm PU |
Panel steel cover | SS, GI, aluminum etc |
