China high effective Spiral Freezing or Spiral IQF Freezer for Meat or Seafood
- FOB Price
US $100000.01 - 2 set
US $7500.03 - 3 set
- group name
- FSL series spiral freezer
- Min Order
- 1 set
- brand name
- First cold chain + freeze food machine
- model
- FSL
- Nearest port for product export
- Tianjin Port, Shanghai Port, Ningbo Port, Qingdao Port
- Delivery clauses under the trade mode
- FOB, CFR, CIF, EXW, CIP, DDP, DAF
- Acceptable payment methods
- T/T, L/C
- update time
- Thu, 21 Nov 2024 18:13:13 GMT
Paramtents
Refrigerant Freon
Structure Assembled
Suitable for Factory
Refrigeration System Brand Compressor Unit
Size Customized
Use Nature Production
Usage Food
Freezer Body Material 304 Stainless Steel
Specification CE ISO9001
Transport Package Seaworthy Plywood Case
Packging & Delivery
-
Min Order1 set
Briefing
Spiral freezer machine is widely applied in bakery . high degree automatic and save space and labor.
better freezer .
better freezer .
Detailed
Spiral Freezing Product Description
- Spiral freezers are mostly used for flour food freezing, meat freezing, seafood freezing and prepared food freezing
- Structure:
- Stainless steel conveyor belt; equipped with safe guard both sides
- Sandwich PUF panels laminated by stainless steel plate both sides floor panels are equipped
- Door is equipped with frame heating device
- Aluminum evaporators, variable fin pitches
- Axial fans: stainless steel air box, aluminum blades
- Complete welded stainless steel water discharging plate will be installed on top of floor panels. It will bring defrosting water out of cabinet through many stainless steel draining pipes
- Drum, inlet device, outlet device and all structure parts are made of stainless steel
- Control panel is made of stainless steel
- Schneider or Siemens electric components
the 1500kg/h spiral freezer parameters as follow:
frozen product :chicken breast
capacity: 1500kg/h
cooling capacity: 255kw (±40℃）
refrigerant :R404A/R507A/R717
inter/out temperature: +15/-18℃
inside room temperature:-38±3℃
freeze time :10-50min (adjust)
the spiral freezer body size: 7*5*3.5m
the materials use full stainless steel structure SUS304
the evaporator use large anti-rust aluminum finned tube group, the rest of the 304 stainless steel
the Electric Control Cabinet use Schneider Electric
the panels use double face stainless steel and Self-extinguishing Flame Retardant Polyurethane 150mm Thickness
the conveyor belt we could use 600mm,650mm,710mm etc ,according to clients choice.
